Supamaxx 7-40 Bollard

Single Mount Removable Bollard

The new technology Supamaxx 7-40 has a small super light weight base plate – 46kg only. This patent pending design is a technology break through in single shallow footing bollard systems of 200mm deep, that will stop a 7.5 ton truck at 40 mph or 64 km at 90 degrees from breaking through the security line.

The 200mm deep shallow single bollard will also reduce the need to re-divert utilities. The system is the most economical on the market and very aesthetically pleasing. This bollard is small and easy to install. This system is designed to follow the contours of the ground and can go around corners. If the post gets damaged after an attack they can be removed from the slipper box and replaced with no need to remove or replace the concrete foundation.

Once fitted the only maintenance is to repaint when needed or the bollard can be covered with a mild or stainless steel shroud.

‘New technology breakthrough – foundation only 200mm deep’

Supamaxx HVM 7-40 Bollard

7-40 Bollard Specification:

Height Above Ground: 900mm

Footing Depth: Only 200mm

Options: Stainless Steel & Mild Steel Shrouds

Commonly used for:

Data Sheet

HVM 7-40 Edit Single Mount Removable Bollard
